ORIGINAL FEED SECTION
[B]
[A]
The document sensor [A] is used to detect the documents when they are set
in the ADF. The sensor [B] is not used in the C226 although it exists.
The ADF unit is a standard unit that is used on many other products.
SM
2-3
C226
