More than one In-Service bit can be set concurrently. Consider the case in which a low priority
interrupt handler is interrupted by a higher-priority interrupt request (the interrupts are nested).
The In-Service bits for both interrupt sources are set when the higher-priority interrupt is ac-
knowledged.
Setting the In-Service bit for an IR line inhibits (masks) further interrupts from that IR line and
all IR lines of a lower priority when the 8259A module is programmed for fully nested operation.
For example, if the 8259A module is programmed for default priority (IR0 highest) and the IR4
In-Service bit is set, then no interrupts are possible from IR4 through IR7 until the In-Service bit
is reset.
The default masking of interrupts by the In-Service Register can be circumvented by using either
Special Fully Nested Mode or Special Mask Mode (described below).
The In-Service bits are cleared by an End-of-Interrupt (EOI) command. The EOI command can
either be sent to the 8259A module by the CPU or be generated automatically by the 8259A mod-
ule itself.
8.3.4.1

Clearing the In-Service Bits: Non-Specific End-Of-Interrupt

The Non-Specific End-of-Interrupt (EOI) command instructs the 8259A module to reset the high-
est-priority In-Service bit. When the 8259A module is operating in Fully Nested Mode, the high-
est-priority In-Service bit always corresponds to the interrupt handler in progress; the 8259A
module does not need to be told explicitly which handler is ending. The Non-Specific EOI is a
shortcut for systems that use the fully nested interrupt structure.
8.3.4.2 Clearing the In-Service Bits: Specific End-Of-Interrupt
Some operating modes of the 8259A module do not use the fully nested interrupt structure. In
these alternate modes, a lower-priority interrupt request can interrupt a higher-priority handler. If
a Non-Specific EOI is issued in this case, the highest-priority In-Service bit is reset even though
the handler for that interrupt has not completed execution. The Specific End-of-Interrupt
(EOI) command instructs the 8259A module to reset a specific bit in the In-Service Register. Sys-
tems that are not using Fully Nested Mode must issue a Specific EOI command to ensure that the
proper In-Service bit is cleared.
8.3.4.3 Automatic End-Of-Interrupt Mode
The 8259A module can be programmed to clear the In-Service Bit for an IR line on the rising
edge of the second INTA pulse of the interrupt acknowledge cycle. When Automatic End-of-In-
terrupt (EOI) Mode is selected, the In-Service bit for any given IR line is set only between the
falling edge of the first INTA pulse and the rising edge of the second INTA pulse.
