Chapter 5. FRONT PANEL
OPERATION
5.1
Introduction
LED
Vacuum Fluorescent
Indicators
Keypad
Display (VFD)
Figure 5-1. CDM-710 Front Panel View (Rev. A and later, L-Band version shown)
Figure 5-1 identifies the key features of the CDM-710 Broadcast Satellite Modem front panel.
The user can fully control and monitor the operation of the CDM-710 using the front panel's LED
indicators, keypad, and display. The CDM-710 features a nested menu system that displays all
available options and prompts the user to carry out a required action.
