Servicing the Battery

The battery operates the clock for the server module.
"Replace the Battery" on page 109
■
Related Information
"Detecting and Managing Faults" on page 5
■
"Preparing for Service" on page 51
■

▼ Replace the Battery

The battery maintains server module time when the server module is powered off. If
the server module fails to maintain the proper time when it is powered off, replace
the battery.
Use a CR2032 replacement battery.
1. Prepare for service.
See "Preparing for Service" on page
2. Push the top of the battery forward, then lift the battery from the holder (panel
1 and 2).
If you need more clearance, remove the DIMM in slot CMP0/BOB3/CH1/D0
(nearest the battery). See
DIMM" on page
51.
"DIMM Configuration" on page 77
80.
and "Remove a
109
