"Diagnostics LEDs" on page 10
■
"Illustrated Parts Breakdown" on page 1
■
4
Netra SPARC T4-1B Server Module Service Manual • June 2012
Description
Amber LED: Fault (Service Action Required)
Green LED: OK
Power button
Reset button: NMI (for service use only)
Green LED: Drive OK
Amber LED: Drive Fault (Service Action Required)
Blue LED: Drive Ready to Remove
Rear chassis power connector
Rear chassis data connection
