▼ Set the Server Module to a Ready-to-Remove
State
1. Log in to Oracle ILOM on the server module you plan to remove.
2. Ensure that the server module is in standby mode, with the host powered off.
-> show /SYS/ power_state
/SYS
properties:
power_state = Off
If you do not see this message, check that you have performed all the steps in
"Shut Down the OS and Host (Commands)" on page
3. Type:
-> set /SYS/ prepare_to_remove_action=true
Set 'prepare_to_remove_action' to 'true'
The server module is in standby mode. Power is removed from the host while
standby power is applied to the SP.
4. Confirm that the server module is in standby mode by viewing the blue Ready
to Remove LED on the front of the server module.
See
to Remove LED is on, the server module is ready for removal from the modular
system chassis.
5. Remove the server module from the chassis.
See
Related Information
"Remove the Server Module From the Modular System" on page 61
■
"Shut Down the OS and Host (Commands)" on page 57
■
"Shut Down the OS and Host (Power Button – Graceful)" on page 59
■
"Shut Down the OS and Host (Emergency Shutdown)" on page 59
■
60 Netra SPARC T4-1B Server Module Service Manual • June 2012
"Front and Rear Panel Components" on page 3
"Remove the Server Module From the Modular System" on page
57.
to locate this LED. If the Ready
61.
