No.
5
6
7
DIMM configuration guidelines:
Use only supported industry-standard DDR-3 DIMMs.
■
Use supported DIMM capacities: 4 Gbyte, 8 Gbyte, and 16 Gbyte.
■
Refer to the Netra SPARC T4-1B Server Module Product Notes for the latest
information.
Install quantities of 4, 8, or 16 DIMMs, in the correct slots:
■
■
■
■
Ensure that all DIMMs have the same part number.
■
Related Information
"Memory Faults" on page 75
■
"Locate a Faulty DIMM" on page 79
■
"Remove a DIMM" on page 80
■
"Install a DIMM" on page 81
■
"Clear the Fault and Verify the Functionality of the Replacement DIMM" on
■
page 82
78 Netra SPARC T4-1B Server Module Service Manual • June 2012
Description or Partial FRU Name
(full names start with /SYS/MB/CMP0/)
DIMMs controlled by BOB0:
CH0/D1
CH0/D0
CH1/D1
CH1/D0
DIMMs controlled by BOB1:
CH1/D0
CH1/D1
CH0/D0
CH0/D1
DIMM Fault LEDs
4 DIMMs: CH1/D0 slots (white sockets)
8 DIMMs: CH1/D0 and CH0/D0 slots
16 DIMMs: All slots
