Front and Rear Panel Components

See "Diagnostics LEDs" on page 10
No. Description
1 RFID tag (provides the serial number of the server module)
2 UCP
3 Drive slots
4 White LED: Locator (functions as the physical presence switch)
5 Blue LED: Ready to Remove
for more information.
Identifying Components 3
