Icom IC-7851 Instruction Manual page 256

18
CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data
1A* 05 0197 00 or 01
0198 see p. 18-11
0199 see p. 18-11
0200 see p. 18-11
0201 see p. 18-11
0202 see p. 18-11
0203 see p. 18-11
0204 see p. 18-11
0205 see p. 18-11
0206 see p. 18-11
0207 see p. 18-11
0208 see p. 18-11
0209 see p. 18-11
0210 see p. 18-11
0211 see p. 18-11
0212 see p. 18-11
0213 see p. 18-11
0214 see p. 18-11
0215 see p. 18-11
0216 see p. 18-11
0217 see p. 18-11
0218 see p. 18-11
0219 see p. 18-11
0220 see p. 18-11
0221 see p. 18-11
0222 see p. 18-11
0223 see p. 18-11
0224 see p. 18-11
0225 see p. 18-11
0226 see p. 18-11
0227 see p. 18-11
0228 see p. 18-11
0229 see p. 18-11
0230 see p. 18-11
0231 see p. 18-11
0232 see p. 18-11
Description
Send/read the Main/Sub scope access
setting linked to the [MAIN]/[SUB] key
operation
(00=OFF, 01=ON)
Send/read scope edge 1 frequencies for 0.03
to 1.60 MHz band
Send/read scope edge 2 frequencies for 0.03
to 1.60 MHz band
Send/read scope edge 3 frequencies for 0.03
to 1.60 MHz band
Send/read scope edge 1 frequencies for 1.60
to 2.00 MHz band
Send/read scope edge 2 frequencies for 1.60
to 2.00 MHz band
Send/read scope edge 3 frequencies for 1.60
to 2.00 MHz band
Send/read scope edge 1 frequencies for 2.00
to 6.00 MHz band
Send/read scope edge 2 frequencies for 2.00
to 6.00 MHz band
Send/read scope edge 3 frequencies for 2.00
to 6.00 MHz band
Send/read scope edge 1 frequencies for 6.00
to 8.00 MHz band
Send/read scope edge 2 frequencies for 6.00
to 8.00 MHz band
Send/read scope edge 3 frequencies for 6.00
to 8.00 MHz band
Send/read scope edge 1 frequencies for 8.00
to 11.00 MHz band
Send/read scope edge 2 frequencies for 8.00
to 11.00 MHz band
Send/read scope edge 3 frequencies for 8.00
to 11.00 MHz band
Send/read scope edge 1 frequencies for
11.00 to 15.00 MHz band
Send/read scope edge 2 frequencies for
11.00 to 15.00 MHz band
Send/read scope edge 3 frequencies for
11.00 to 15.00 MHz band
Send/read scope edge 1 frequencies for
15.00 to 20.00 MHz band
Send/read scope edge 2 frequencies for
15.00 to 20.00 MHz band
Send/read scope edge 3 frequencies for
15.00 to 20.00 MHz band
Send/read scope edge 1 frequencies for
20.00 to 22.00 MHz band
Send/read scope edge 2 frequencies for
20.00 to 22.00 MHz band
Send/read scope edge 3 frequencies for
20.00 to 22.00 MHz band
Send/read scope edge 1 frequencies for
22.00 to 26.00 MHz band
Send/read scope edge 2 frequencies for
22.00 to 26.00 MHz band
Send/read scope edge 3 frequencies for
22.00 to 26.00 MHz band
Send/read scope edge 1 frequencies for
26.00 to 30.00 MHz band
Send/read scope edge 2 frequencies for
26.00 to 30.00 MHz band
Send/read scope edge 3 frequencies for
26.00 to 30.00 MHz band
Send/read scope edge 1 frequencies for
30.00 to 45.00 MHz band
Send/read scope edge 2 frequencies for
30.00 to 45.00 MHz band
Send/read scope edge 2 frequencies for
30.00 to 45.00 MHz band
Send/read scope edge 1 frequencies for
45.00 to 60.00 MHz band
Send/read scope edge 2 frequencies for
45.00 to 60.00 MHz band
Cmd. Sub Cmd. Data
1A* 05 0233 see p. 18-11
0234 00 or 01
0235 00 or 01
0236 01 to 15
0237 00 or 01
0238 00 or 01
0239 00 or 01
0240 00 or 01
0241 00 or 01
0242 00 or 01
0243 00 to 03
0244 00 to 03
0245 05 to 30
0246 03 to 10
0247 00
01
02
03
04
0248 01 to 08
0249 0001 to
9999
0250 01 to 60
0251 28 to 45
0252 00 to 03
0253 00 or 01
0254 00 to 02
0255 00 or 01
0256 00 to 03
0257 see p. 18-11
0258 00 or 01
0259 00 or 01
18-8
Description
Send/read scope edge 3 frequencies for
45.00 to 60.00 MHz band
Send/read the voice 1st menu.
(00=VOICE-Root, 01=VOICE-PLAY)
Send/read the auto monitor function setting
when transmitting a recorded voice memory
(00=OFF, 01=ON)
Send/read the repeat interval to transmit the
recorded voice audio
(01=1 sec. to 15=15 sec.)
Send/read the QSO recording device setting
(00=SD card, 01=USB flash drive)
Send/read the recording mode.
(00=TX&RX, 01=RX Only)
Send/read recording TX audio for the QSO
recorder
(00=Microphone audio, 01=TX monitor audio)
Send/read the squelch relation to recording
RX audio for the QSO recorder
(00=Always, 01=Squelch Auto)
Send/read the QSO record file split function
setting (00=OFF, 01=ON)
Send/read the PTT Automatic Recording
function setting (00=OFF, 01=ON)
Send/read the RX audio recording status for
the PTT Automatic Recording function
( 00=OFF (records no RX audio),
01=Records the RX audio just before 5 sec.,
02=Records the RX audio just before 10 sec.,
03=Records the RX audio just before 15 sec.)
Send/read QSO PLAY Skip time
(00=3 sec., 01=5 sec., 02=10 sec., 03=30 sec.)
Send/read the instant record time when
[REC] is pushed
(05=5 sec. to 30=30 sec.)
Send/read the instant playback time when
[PLAY] is pushed
(03=3 sec. to 10=10 sec.)
Normal selection for contest number style
"190→ANO" selection for contest number
style
"190→ANT" selection for contest number
style
"90→NO" selection for contest number style
"90→NT" selection for contest number style
Send/read count up trigger channel
( 01=M1, 02=M2, 03=M3, 04=M4, 05=M5,
06=M6, 07=M7, 08=M8)
Send/read present number
(0001=1 to 9999=9999)
Send/read CW keyer repeat time
(01=1 sec. to 60=60 sec.)
Send/read CW keyer dot/dash ratio
(28=1:1:2.8 to 45=1:1:4.5)
Send/read rise time
( 00=2 msec., 01=4 msec., 02=6 msec.,
03=8 msec.)
Send/read paddle polarity
(00=Normal, 01=Reverse)
Send/read keyer type
(00=Straight, 01=Bug-key, 02=ELEC-Key)
Send/read mic. up/down keyer set
(00=OFF, 01=ON)
Send/read averaging function for RTTY FFT
scope
( 00=OFF,
01=Averaging the two observations,
02=Averaging the three observations,
03=Averaging the four observations)
Send/read RTTY FFT scope waveform color
Send/read RTTY decode USOS
(00=OFF, 01=ON)
Send/read RTTY decode new line code
(00=CR,LF,CR+LF, 01=CR+LF)
