Icom IC-7851 Instruction Manual page 218

■ ACC set screen (continued)
ACC-B AF Beep/Speech... Output
Select "ON" to output the Beep and Speech audio
from [B ACC1].
• OFF: Beep and Speech audio are not output from [B
ACC1].
• ON: Beep and Speech audio are output from [B
ACC1].
• Setting the [ACC-B AF SQL Output Select] item is neces-
sary.
• The beep level is limited when the [Beep Level Limit] is
ON.
• The side tone level is limited when the [Side Tone Level
Limit] is ON.
ACC-B IF Output Level
Sets the IF output level of [B ACC1].
• Range: 0%–100% (in 1% steps)
S/PDIF Output Select
Selects the signal output from [S/P DIF].
• AF: AF signal is output from [S/P DIF].
• IF: IF signal is output from [S/P DIF].
S/PDIF AF/IF XFC Output (SPLIT ON)
Selects the signal output from [S/P DIF] while [XFC] is
held down in the split operation.
• MAIN: Main band's AF/IF signal.
• SUB: Sub band's AF/IF signal.
• When "MAIN" is selected, the
• When "SUB" is selected, the
S/PDIF AF Output Level
Sets the [S/P DIF] output level.
• Range: 0 to 100% (in 1% steps)
S/PDIF AF SQL
Select the squelch behavior of [S/P DIF].
• OFF(OPEN): The squelch is always opened regard-
less of the transceiver's squelch con-
dition.
• ON: The squelch opens and closes, ac-
cording to the transceiver's squelch
condition.
(Default: OFF)
(Default: 50%)
(Default: AF)
(Default: SUB)
Sub band audio is muted.
Main band audio is muted.
(Default: 50%)
(Default: OFF(OPEN))
S/PDIF AF Beep/Speech... Output
Select "ON" to output the Beep and Speech audio
from [S/P DIF].
• OFF: Beep and Speech audio are not output from
[S/P DIF].
• ON: Beep and Speech audio are output from [S/P
DIF].
S/PDIF IF Output Level
Sets the IF output level of [S/P DIF].
• Range: 0 to 100% (in 1% steps)
USB Output Select
Selects the [USB B] output signal.
• AF: AF signal is output from [USB B].
• IF: IF signal is output from [USB B].
USB AF/IF XFC Output (SPLIT ON)
Selects the signal output from [USB B] while [XFC] is
held down in the split operation.
• MAIN: Main band's AF/IF signal.
• SUB: Sub band's AF/IF signal.
• When "MAIN" is selected, the
• When "SUB" is selected, the
USB AF Output Level
Sets the [USB B] output level.
• Range: 0 to 100% (in 1% steps)
USB AF SQL
Select the squelch behavior of [USB B].
• OFF(OPEN): The squelch is always opened regard-
less of the transceiver's squelch con-
dition.
•ON: The squelch opens and closes, ac-
cording to the transceiver's squelch
condition.
USB AF Beep/Speech... Output
Select "ON" to output the Beep and Speech audio
from [USB B].
• OFF: Beep and Speech audio are not output from
[USB B].
• ON: Beep and Speech audio are output from [USB B].
• The beep level is limited when the [Beep Level Limit] is ON.
• The side tone level is limited when the [Side Tone Level
Limit] is ON.
15-7
15
SET MODE
(Default: OFF)
(Default: 50%)
(Default: AF)
(Default: SUB)
Sub band audio is muted.
Main band audio is muted.
(Default: 50%)
(Default: OFF(OPEN))
(Default: OFF)
