D Command table (continued)
Cmd. Sub Cmd. Data
1A* 05 0148 00 or 01
0149 00 or 01
0150 00 or 01
0151 00 or 01
0152 00 or 01
0153 00 or 01
0154 00 or 01
0155 00 or 01
0156 0000 to
0223
0157 00 or 01
0158 00 or 01
0159 00 to 03
0160 00 to 04
0161 00 to 04
0162 00 to 04
0163 00 to 10
0164 0010 to
0100
0165 00 to 31
0166 00 to 02
0167 00 or 01
0168 00 or 01
0169
0170
0171 01 to 30
Description
Send/read external keypad set for voice
memory (00=OFF, 01=ON)
Send/read external keypad set for memory
keyer (00=OFF, 01=ON)
Send/read screen capture by the [POWER]
switch (00=OFF, 01=ON)
Send/read screen capture by the [Print
Screen] key on the keyboard
(00=OFF, 01=ON)
Send/read captured screen image data
saving memory device
(00=SD card, 01=USB flash drive)
Send/read screen capture image data saving
format (00=PNG format, 01=BMP format)
Send/read the Shutdown function
(00=Shutdown, 01=Standby/Shutdown)
Send/read CI-V transceive set
(00=OFF, 01=ON)
Send/read the transceive CI-V Address for
LAN to REMOTE in hexadecimal code
(0000=00h to 0223=DFh)
Send/read antenna controller status
(frequency, and so on) data output from
[REMOTE] (00=OFF, 01=ON)
Send/read echo back setting for CI-V
operation (00=ON, 01=OFF)
Send/read data transfer speed for RTTY or
PSK decode output from USB B
( 00=4800 bps, 01=9600 bps, 02=19200 bps,
03=38400 bps)
Send/read transmission control line setting
for USB B
( 00=OFF, 01=USB1 DTR, 02=USB1 RTS,
03=USB2 DTR, 04=USB2 RTS)
* Different line must be set from both CW
keying and RTTY (FSK)
Send/read CW keying line setting for USB B
( 00=OFF, 01=USB1 DTR, 02=USB1 RTS,
03=USB2 DTR, 04=USB2 RTS)
* Different line must be set from both
transmission control and RTTY (FSK)
Send/read RTTY (FSK) line setting for USB B
( 00=OFF, 01=USB1 DTR, 02=USB1 RTS,
03=USB2 DTR, 04=USB2 RTS)
* Different line must be set from both CW
keying and transmission control
Send/read keyboard type
( 00=English, 01=Japanese,
02=United Kingdom, 03=French, 04=French
(Canadian), 05=German, 06=Portuguese,
07=Portuguese (Brazilian), 08=Spanish,
09=Spanish (Latin American), 10=Italian)
Send/read keyboard repeat delay
( 0010=100 msec., 0100=1000 msec.
; 50 msec. steps)
Send/read keyboard repeat rate
(00=2.0 cps to 31=30.0 cps)
Send/read mouse pointer speed
(00=Slow, 01=Mid, 02=Fast)
Send/read mouse pointer speed acceleration
(00=OFF, 01=ON)
Send/read DHCP client setting (auto IP
address setting using DHCP server)
(00=OFF, 01=ON)
Send/read IP address setting (fixed setting)
( 0000000000000001 (0.0.0.1) to
0255025502550254 (255.255.255.254))
*Usable when the DHCP client setting is OFF
Read the IP address set by the DHCP server
( 0000000000000001 (0.0.0.1) to
0255025502550254 (255.255.255.254))
* If the DHCP client setting is OFF, sends
back the manually set IP address (fixed IP
address)
Send/read subnet mask
(01=128.0.0.0 to 30=255.255.255.252)
Cmd. Sub Cmd. Data
1A* 05 0172
0173
0174
0175 see p. 18-11
0176 00 or 01
0177 000001 to
065535
0178 000001 to
065535
0179 000001 to
065535
0180 00 or 01
0181 see p. 18-11
0182 00 or 01
0183 00 to 02
0184 00 to 02
0185 00 or 01
0186 00 or 01
0187 00 to 03
0188 00 or 01
0189 see p. 18-11
0190 see p. 18-11
0191 see p. 18-11
0192 00 or 01
0193 00 to 02
0194 00 to 02
0195 00 to 09
0196 00 or 01
18-7
CONTROL COMMAND
Description
Send/read default gateway
( 0000000000000001 (0.0.0.1) to
0255025502550254 (255.255.255.254),
FF=Blank)
*Usable when the DHCP client setting is OFF
Send/read primary DNS (Domain Name
System) server address
( 0000000000000001 (0.0.0.1) to
0255025502550254 (255.255.255.254),
FF=Blank)
*Usable when the DHCP client setting is OFF
Send/read secondly DNS (Domain Name
System) server address
( 0000000000000001 (0.0.0.1) to
0255025502550254 (255.255.255.254),
FF=Blank)
*Usable when the DHCP client setting is OFF
Send/read network name when remotely
operating using the optional RS-BA1
(up to 15-character)
Send/read the remote control setting
(00=OFF, 01=ON)
Send/read the control port setting by
accessing from internet
(000001=1 to 065535=65535)
Send/read the serial port setting by
accessing from internet
(000001=1 to 065535=65535)
Send/read the audio port setting by
accessing from internet
(000001=1 to 065535=65535)
Send/read the internet access line setting
( 00=FTTH (Fiber To The Home),
01=ADSL/CATV)
Send/read Network radio name
(up to 16-character)
Send/read scope indication during TX
(00=OFF, 01=ON)
Send/read scope max. hold
(00=OFF, 01=ON)
Send/read scope center frequency set
( 00=Filter center, 01=Carrier point center,
02=Carrier point center (Abs. Freq.))
Send/read scope marker position setting
during fix type scope
(00=Filter center, 01 Carrier point)
Send/read external monitor signal width
(00=Narrow, 01=Wide)
Send/read averaging function for spectrum
scope
( 00=OFF,
01=Averaging the two observations,
02=Averaging the three observations,
03=Averaging the four observations)
Send/read spectrum display type
(00=Fill, 01=Fill+Line)
Send/read spectrum fill color
Send/read spectrum line color
Send/read spectrum color for peak hold
Send/read waterfall set for spectrum scope
(00=OFF, 01=ON)
Send/read waterfall speed
(00=Slow, 01=Mid, 02=Fast)
Send/read waterfall height when expanded
scope is selected
(00=Small, 01=Mid, 02=Larger)
Send/read peak color level set for waterfall of
the spectrum scope
( 00=Grid 1, 01=Grid 2, 02=Grid 3, 03=Grid 4,
04=Grid 5, 05=Grid 6, 06=Grid 7, 07=Grid 8,
08=Grid 9, 09=Grid 10)
Send/read the Main and Sub scope screen
arrangement during dual scope
(00=Up and down, 01=Left and right)
