Icom IC-7851 Instruction Manual page 215

15
SET MODE
■ Level set screen
SSB RX HPF/LPF
Sets the receive audio high-pass filter and low-pass
filter cut-off frequency in 100 Hz steps.
Selectable ranges:
• HPF: Between 100 Hz and 2000 Hz
• LPF: Between 500 Hz and 2400 Hz
If this item is set, the [SSB RX Tone (Bass)] and
[SSB RX Tone (Treble)] items cannot be set.
SSB RX Tone (Bass)
Sets the bass level of the receive audio tone in the
SSB mode from –5 to +5.
SSB RX Tone (Treble)
Sets the treble level of the receive audio tone in the
SSB mode from –5 to +5.
AM RX HPF/LPF
Sets the receive audio high-pass filter or low-pass filter
cut-off frequency in 100 Hz steps.
Selectable ranges:
• HPF: Between 100 Hz and 2000 Hz
• LPF: Between 500 Hz and 2400 Hz
If this item is set, the [AM RX Tone (Bass)] and [AM
RX Tone (Treble)] items cannot be set.
AM RX Tone (Bass)
Sets the bass level of the receive audio tone in the AM
mode from –5 to +5.
AM RX Tone (Treble)
Sets the treble level of the receive audio tone in the
AM mode from –5 to +5.
FM RX HPF/LPF
Sets the receive audio high-pass filter or low-pass filter
cut-off frequency in 100 Hz steps.
Selectable ranges:
• HPF: Between 100 Hz and 2000 Hz
• LPF: Between 500 Hz and 2400 Hz
If this item is set, the [FM RX Tone (Bass)] and [FM
RX Tone (Treble)] items cannot be set.
FM RX Tone (Bass)
Sets the bass level of the receive audio tone in the FM
mode from –5 to +5.
(Default: – – – – – – –)
(Default: 0)
(Default: 0)
(Default: – – – – – – –)
(Default: 0)
(Default: 0)
(Default: – – – – – – –)
(Default: 0)
FM RX Tone (Treble)
Sets the treble level of the receive audio tone in the
FM mode from –5 to +5.
CW RX HPF/LPF
Sets the receive audio high-pass filter or low-pass filter
cut-off frequency in 100 Hz steps.
Selectable ranges:
• HPF: Between 100 Hz and 2000 Hz
• LPF: Between 500 Hz and 2400 Hz
RTTY RX HPF/LPF
Sets the receive audio high-pass filter or low-pass filter
cut-off frequency in 100 Hz steps.
Selectable ranges:
• HPF: Between 100 Hz and 2000 Hz
• LPF: Between 500 Hz and 2400 Hz
PSK RX HPF/LPF
Sets the receive audio high-pass filter or low-pass filter
cut-off frequency in 100 Hz steps.
Selectable ranges:
• HPF: Between 100 Hz and 2000 Hz
• LPF: Between 500 Hz and 2400 Hz
SSB TX Tone (Bass)
Sets the bass level of the transmit audio tone in the
SSB mode from –5 to +5.
SSB TX Tone (Treble)
Sets the treble level of the transmit audio tone in the
SSB mode from –5 to +5.
AM TX Tone (Bass)
Sets the bass level of the transmit audio tone in the
AM mode from –5 to +5.
AM TX Tone (Treble)
Sets the treble level of the transmit audio tone in the
AM mode from –5 to +5.
15-4
(Default: 0)
(Default: – – – – – – –)
(Default: – – – – – – –)
(Default: – – – – – – –)
(Default: 0)
(Default: 0)
(Default: 0)
(Default: 0)
