Memory Configuration Submenu - Congatec COM Express conga-TC87 User Manual

Feature
DMI IOT

Memory Configuration Submenu

11.5.2.2
Feature
Memory Frequency
Total Memory
Memory Voltage
DIMM#0 (Bottom)
DIMM#2 (Top)
CAS Latency (tCL)
CAS to RAS (tRCDmin) no option
Row Precharge
(tRPmin)
Active to Precharge
(tRASmin)
DIMM Profile
►Custom Profile
Control
Memory Frequency
Limiter
DDR Reset Wait Time
Max TOLUD
Enh Interleave Support
RI Support
DLL Weak Lock Support Disabled
Mc Lock
Ch Hash Support
Copyright © 2013 congatec AG
Options Description
Enabled Enable or disable DMI IOT.
Disabled
Options Description
no option Displays the memory frequency.
no option Displays the total amount of installed memory.
no option Displays the memory voltage.
no option Displays bottom memory socket DIMM information.
no option Displays top memory socket DIMM information.
no option Displays the CAS Latency (tCL).
Displays the CAS to RAS (tRCDmin).
no option Displays the Row Precharge (tRPmin).
no option Displays the Active to Precharge (tRASmin).
Default DIMM Profile Select the DIMM timing profile that should be used. XMP profiles cannot work on current modules and
Custom Profile
MUST not be selected.
XMP Profile 1
CAUTION: For congatec internal debugging only. DO NOT CHANGE.
XMP Profile 2
Configure the custom DIMM profile options.
Submenu
CAUTION: For congatec internal debugging only. DO NOT CHANGE.
Maximum memory frequency selections in [MHz] (Hidden if DIMM profile is set to 'Custom Profile').
Auto, 1067,1333, 1600,
1867, 2133, 2400, 2667
0-3000000 The amount of time (in nano seconds) to wait for switch DDR voltage.
Default : 0
Maximum value of TOLUD Dynamic assignment would adjust TOLUD automatically based on largest
Dynamic, 1 GB, 1.25 GB,
1.5 GB, MMIO length of installed graphic controller.
1.75 GB, 2 GB, 2.25 GB,
2.5 GB, 2.75 GB, 3 GB,
3.25 GB
Disabled Enable or disable Enhanced Interleave support.
Enabled
Disabled Enable or disable Rank Interleave support. Note: RI and HORI can not be enabled at the same time.
Enabled
Enable or disable DLL weak lock support.
Enabled
Disabled Enable or disable capacity to lock or not MC registers.
Enabled
Disabled Enable or disable channel hash support. Note: Only if memory interleaved mode.
Enabled
TU87m12 105/114
