Feature
Board Capability
DeepSx Power Policies
GP27 Wake From DeepSx
PCIe Wake From DeepSx
Serial IRQ Mode
SB CRID
PCH Cross Throttling
SLP_S4 Assertion Width
Port 80h Redirection
Copyright © 2013 congatec AG
Options Description
SUS_PWR_DN_ACK = Send disabled to PCH.
SUS_PWR_DN_ACK
DeepSx DeepSx = Show DeepSx policies.
Configure the DeepSx mode configuration.
Disabled
Enabled in S5/Battery
Enabled in S4-S5/Battery
Enabled in S3-S4-S5/Battery
Disabled Wake from DeepSx by the assertion of GP27 pin.
Enabled
Disabled Wake from DeepSx by the assertion of PCIe.
Enabled
Configure serial IRQ mode.
Quiet
Continuous
Disabled Enable or disable southbridge compatible revision ID support.
Enabled
Disabled Enable or disable the PCH cross throttling feature.
Enabled
Select a minimum assertion width of the SLP_S4# signal.
Disabled
1-2 Seconds
2-3 Seconds
3-4 Seconds
4-5 Seconds
LPC Bus Control where the port 80h cycles are sent.
PCIe Bus
