Software Feature Mask Configuration Submenu

11.4.10.1
Feature
RAID0
RAID1
RAID10
RAID5
Intel Rapid Recovery
Technology
Option ROM UI and Banner
HDD Unlock
LED Locate
IRRT Only on eSATA
Intel Smart Response
Technology
Option ROM UI Delay
11.4.11

Intel(R) Rapid Start Technology Submenu

Feature
Intel(R) Rapid Start Technology Disabled
No valid partition
Entry on S3 RTC Wake
Entry After
Active Page Threshold Support
Active Memory Threshold
Copyright © 2013 congatec AG
Options Description
Disabled Enable or disable RAID0 feature.
Enabled
Disabled Enable or disable RAID1 feature.
Enabled
Disabled Enable or disable RAID10 feature.
Enabled
Disabled Enable or disable RAID5 feature.
Enabled
Disabled Enable or disable Intel Rapid Recovery Technology.
Enabled
Disabled If enabled, then the option ROM user interface is shown. Otherwise, no option ROM banner or information
Enabled
will be displayed if all disks and RAID volumes are normal.
Disabled If enabled, indicates that the HDD password unlock in the OS is enabled.
Enabled
Disabled LED locate
Enabled
Disabled If enabled, then only Intel Rapid Recovery Technology (IRRT) volumes can span internal and external SATA
Enabled
(eSATA) drives. If disabled, then any RAID volume can span internal and eSATA drives.
Disabled Enable or disable Intel Smart Response Technology.
Enabled
2 Seconds If enabled, indicates the delay of the option ROM user interface splash screen in a normal status.
4 Seconds
6 Seconds
8 Seconds
Options Description
Enable or disable Intel(R) Rapid Start Technology.
Enabled
no option Warning message when the Intel(R) Rapid Start Technology is not completely set up.
Disabled Rapid Start invocation upon S3 RTC wake.
Enabled
0-120 Enable RTC wake timer at S3 entry. Value range is from 0 (immediately) to 120 minutes.
Default : 10
Disabled Support RST with small partition.
Enabled
0-65535 Try to support RST when partition size > Active Page Threshold size in MB. Value 0 means automatic
Default : 0 mode.
