2.5.7 Intel Celeron
conga-TC87 Art. No. 046904
(GT2 Graphics)
Max Turbo Frequency
Memory Size
Operating System
Power Consumption (Amperes/Watts)
Peak Power Consumption
2.6

Supply Voltage Battery Power

• 2.0V-3.5V DC
• Typical 3V DC
2.6.1

CMOS Battery Power Consumption

The CMOS battery power consumption value listed above should not be used to calculate CMOS battery lifetime. You should measure the
CMOS battery power consumption in your customer specific application in worst case conditions, for example during high temperature and high
battery voltage. The self-discharge of the battery must also be considered when determining CMOS battery lifetime. For more information about
calculating CMOS battery lifetime refer to application note AN9_RTC_Battery_Lifetime.pdf on congatec AG website at www.congatec.com.
Note
The CMOS battery consumption of the conga-TC87 revision C.x and earlier draw significantly high current as shown in the table above. This
is due to the fact that the PM_PCH_PWROK signal on revision C.x and earlier is not terminated to ground.
This issue will be corrected with conga-TC87 hardware revisions D.x and later. Contact congatec technical support department for more
information about this topic.
Copyright © 2013 congatec AG
2980U 1.6 GHz Dual Core™ 2MB Cache (VGA)
N.A
2 x 2GB
Windows 7 (64 bit)
Desktop Idle
100% workload
(turbo mode disabled)
100% CPU and GPU workload
(turbo mode disabled)
TBD
RTC @ 20ºC
Integrated in the Intel ® 8 Series PCH-LP
® ®
Intel Celeron 2980U 1.6 GHz 2 Core™ 2MB Intel
22nm
Layout Rev. TU87LB1 /BIOS Rev. TU87R005
TBD Suspend to Ram (S3) 5V Input
Power
TBD 100% Workload
(turbo mode enabled)
TBD 100% CPU and GPU workload
(turbo mode enabled)
Voltage Current
3V DC 9 µA
TU87m12
®
Smart Cache
TBD
N.A
N.A
