Congatec COM Express conga-TC87 User Manual page 70

Pin Row C
DDI3_DDC_AUX_SEL (*)
C38
DDI3_PAIR0+ (*)
C39
DDI3_PAIR0- (*)
C40
C41 GND (FIXED)
DDI3_PAIR1+ (*)
C42
DDI3_PAIR1- (*)
C43
DDI3_HPD
C44
C45 RSVD
DDI3_PAIR2+ (*)
C46
DDI3_PAIR2- (*)
C47
C48 RSVD
DDI3_PAIR3+ (*)
C49
DDI3_PAIR3- (*)
C50
C51 GND (FIXED)
PEG_RX0+ (*)
C52
PEG_RX0- (*)
C53
TYPE0#
C54
PEG_RX1+ (*)
C55
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-TC87.
Copyright © 2013 congatec AG
Pin Row D Pin
D38 RSVD C93
DDI2_PAIR0+
D39 C94
DDI2_PAIR0-
D40 C95
D41 GND (FIXED) C96
DDI2_PAIR1+
D42 C97
DDI2_PAIR1-
D43 C98
DDI2_HPD
D44 C99
D45 RSVD C100
DDI2_PAIR2+
D46 C101
DDI2_PAIR2-
D47 C102
D48 RSVD C103
DDI2_PAIR3+
D49 C104
DDI2_PAIR3-
D50 C105
D51 GND (FIXED) C106
PEG_TX0+ (*)
D52 C107
PEG_TX0- (*)
D53 C108
PEG_LANE_RV# (*)
D54 C109
PEG_TX1+ (*)
D55 C110
TU87m12
Row C Pin Row D
GND D93 GND
PEG_RX13+ (*) PEG_TX13+ (*)
D94
PEG_RX13- (*) PEG_TX13- (*)
D95
GND D96 GND
RVSD D97 RSVD
PEG_RX14+ (*) PEG_TX14+ (*)
D98
PEG_RX14- (*) PEG_TX14- (*)
D99
GND (FIXED) D100 GND (FIXED)
PEG_RX15+ (*) D101 PEG_TX15+ (*)
PEG_RX15- (*) D102 PEG_TX15- (*)
GND D103 GND
VCC_12V D104 VCC_12V
VCC_12V D105 VCC_12V
VCC_12V D106 VCC_12V
VCC_12V D107 VCC_12V
VCC_12V D108 VCC_12V
VCC_12V D109 VCC_12V
GND (FIXED) D110 GND (FIXED)
70/114
