11.5.2

Processor (Integrated Components) Submenu

Feature
Processor Codename
VT-d Capability
VT-d
Thermal Device
(B0:D4:F0)
Audio Device
(B0:D3:F0)
NB CRID
BDAT ACPI Table
Support
►DMI Configuration
►Memory Configuration submenu
►GT - Power
Management Control

DMI Configuration Submenu

11.5.2.1
Feature
DMI
DMI Vc1 Control
DMI Vcp Control
DMI Vcm Control
DMI Link ASPM
Processor Side
DMI Extended Synch
Control
DMI Gen 2
DMI De-emphasis
Control
Copyright © 2013 congatec AG
Options Description
no option Displays the Processor codename.
no option Displays whether the VT-d is supported by the Processor.
Disabled Enable or disable VT-d support.
Enabled Displayed only if the VT-d capability is supported by the Processor.
Enabled Enable or disable thermal device.
Disabled
Enabled Enable or disable the integrated audio device in the Processor.
Disabled
Disabled Enable or disable northbridge compatible revision ID support.
Enabled
Enabled Enable support for the BDAT ACPI table.
Disabled
submenu Control various DMI functions.
DMI link is the main, but exclusively internal bus between the Processor and Platform Controller Hub (PCH).
Memory configuration parameters
submenu Processor Graphics Controller (GT) power management control options
Options Description
no option Displays the DMI bus characteristics.
Enabled Enable or disable DMI Vc1.
Disabled
Enabled Enable or disable DMI Vcp.
Disabled
Enabled Enable or disable DMI Vcm.
Disabled
Disabled Active State Power Management (ASPM) of the DMI link on the
L0s Processor side.
L1 DMI link is the main bus between the Processor and Platform Controller Hub (PCH).
L0sL1
Enabled Enable or disable DMI extended synchronization.
Disabled
Auto Enable or disable DMI Gen2.
Enabled
Disabled
Configure the de-emphasis control on DMI.
-6 dB
-3.5 dB
