Gigabit Ethernet Pin # Description
GBE0_CTREF
A14
Note
The GBE0_LINK# output is only active during a 100Mbit or 1Gbit connection, it is not active during a 10Mbit connection. This is a limitation
of Ethernet controller since it only has 3 LED outputs, ACT#, LINK100# and LINK1000#. The GBE0_LINK# signal is a logic AND of the
GBE0_LINK100# and GBE0_LINK1000# signals on the conga-TC87 module.
Table 6
Serial ATA Signal Descriptions
Signal
Pin # Description
SATA0_RX+
A19
SATA0_RX-
A20
SATA0_TX+
A16
SATA0_TX-
A17
SATA1_RX+
B19
SATA1_RX-
B20
SATA1_TX+
B16
SATA1_TX-
B17
SATA2_RX+
A25
SATA2_RX-
A26
SATA2_TX+
A22
SATA2_TX-
A23
SATA3_RX+
B25
SATA3_RX-
B26
SATA3_TX+
B22
SATA3_TX-
B23
(S)ATA_ACT# A28
Copyright © 2013 congatec AG
Reference voltage for Carrier Board Ethernet channel 0 magnetics center tap. The reference voltage is
determined by the requirements of the module PHY and may be as low as 0V and as high as 3.3V. The
reference voltage output shall be current limited on the module. In the case in which the reference is shorted
to ground, the current shall be limited to 250mA or less.
Serial ATA channel 0, Receive Input differential pair.
Serial ATA channel 0, Transmit Output differential pair.
Serial ATA channel 1, Receive Input differential pair.
Serial ATA channel 1, Transmit Output differential pair.
Serial ATA channel 2, Receive Input differential pair.
Serial ATA channel 2, Transmit Output differential pair.
Serial ATA channel 3, Receive Input differential pair.
Serial ATA channel 3, Transmit Output differential pair.
ATA (parallel and serial) or SAS activity indicator, active low. I/O 3.3v
I/O
PU/PD
I SATA
O SATA
I SATA
O SATA
I SATA
O SATA
I SATA
O SATA
TU87m12
I/O
PU/PD Comment
Comment
Supports Serial ATA specification, Revision 3.0
Supports Serial ATA specification, Revision 3.0
Supports Serial ATA specification, Revision 3.0
Supports Serial ATA specification, Revision 3.0
Supports Serial ATA specification, Revision 3.0
Supports Serial ATA specification, Revision 3.0
Supports Serial ATA specification, Revision 3.0
Supports Serial ATA specification, Revision 3.0
Not connected
50/114
