11.3.1

Platform Information Submenu

The platform information submenu offers additional hardware and software information.
Feature
Processor Information
Processor Type
Codename
Processor Speed
Processor Signature
Stepping
Processor Cores
Microcode Revision
IGD HW Version
IGD VBIOS Version
Total Memory
PCH Information
Codename
PCH SKU
Stepping
11.4

Advanced Setup

Select the advanced tab from the setup menu to enter the advanced BIOS setup screen. The menu is used for setting advanced features and
only features described within this user's guide are listed.
Main Advanced
Graphics
Watchdog
Module Serial Ports
Hardware Health Monitoring
PCI & PCI Express
ACPI
RTC Wake
Trusted Computing
CPU
SATA
Intel(R) Rapid Start Technology
Copyright © 2013 congatec AG
Options Description
no option Subtitle
Displays the processor ID string. The "Processor Type" text itself is not displayed just the ID string.
no option
no option Displays the processor codename
no option Displays the processor speed.
no option Displays the processor signature.
no option Displays the processor stepping.
no option Displays the number of processor cores.
no option Displays the processor microcode revision .
no option Displays the version of the graphics controller.
no option Displays the video BIOS version.
no option Displays the total amount of installed memory.
no option subtitle
no option Displays the codename of the platform controller hub (PCH).
no option Displays the SKU name of the PCH.
no option Displays the PCH stepping.
Chipset Boot
TU87m12
Security Save & Exit
