Table 25 Hdmi Signal Descriptions - Congatec COM Express conga-TC87 User Manual

Table 25 HDMI Signal Descriptions
Signal Pin # Description
TMDS1_CLK +
D36
TMDS1_CLK -
D37
TMDS1_DATA0+
D32
TMDS1_DATA0-
D33
TMDS1_DATA1+
D29
TMDS1_DATA1-
D30
TMDS1_DATA2+
D26
TMDS1_DATA2-
D27
HDMI1_HPD
C24
HDMI1_CTRLCLK
D15
HDMI1_CTRLDATA
D16
TMDS2_CLK +
D49
TMDS2_CLK -
D50
TMDS2_DATA0+
D46
TMDS2_DATA0-
D47
TMDS2_DATA1+
D42
TMDS2_DATA1-
D43
TMDS2_DATA2+
D39
TMDS2_DATA2-
D40
HDMI2_HPD
D44
HDMI2_CTRLCLK
C32
HDM12_CTRLDATA
C33
TMDS3_CLK +
C49
TMDS3_CLK -
C50
TMDS3_DATA0+
C46
TMDS3_DATA0-
C47
TMDS3_DATA1+
C42
TMDS3_DATA1-
C43
TMDS3_DATA2+
C39
TMDS3_DATA2-
C40
HDMI3_HPD
C44
HDMI3_CTRLCLK
C36
Copyright © 2013 congatec AG
HDMI/DVI TMDS Clock output differential pair.
Multiplexed with DDI1_PAIR3+ and DDI1_PAIR3-.
HDMI/DVI TMDS differential pair.
Multiplexed with DDI1_PAIR2+ and DDI1_PAIR2-.
HDMI/DVI TMDS differential pair.
Multiplexed with DDI1_PAIR1+ and DDI1_PAIR1-..
HDMI/DVI TMDS differential pair.
Multiplexed with DDI1_PAIR0+ and DDI1_PAIR0-.
HDMI/DVI Hot-plug detect.
Multiplexed with DDI1_HPD.
HDMI/DVI I 2 C Control Clock
Multiplexed with DDI1_CTRLCLK_AUX+
2
HDMI/DVI I C Control Data
Multiplexed with DDI1_CTRLDATA_AUX-
HDMI/DVI TMDS Clock output differential pair..
Multiplexed with DDI2_PAIR3+ and DDI2_PAIR3-.
HDMI/DVI TMDS differential pair.
Multiplexed with DDI2_PAIR2+ and DDI2_PAIR2-.
HDMI/DVI TMDS differential pair.
Multiplexed with DDI2_PAIR1+ and DDI2_PAIR1-.
HDMI/DVI TMDS differential pair.
Multiplexed with DDI2_PAIR0+ and DDI2_PAIR0-..
HDMI/DVI Hot-plug detect.
Multiplexed with DDI2_HPD
2
HDMI/DVI I C Control Clock
Multiplexed with DDI2_CTRLCLK_AUX+
HDMI/DVI I 2 C Control Data
Multiplexed with DDI2_CTRLDATA_AUX-
HDMI/DVI TMDS Clock output differential pair..
Multiplexed with DDI3_PAIR3+ and DDI3_PAIR3-.
HDMI/DVI TMDS differential pair.
Multiplexed with DDI3_PAIR2+ and DDI3_PAIR2-.
HDMI/DVI TMDS differential pair.
Multiplexed with DDI3_PAIR1+ and DDI3_PAIR1-..
HDMI/DVI TMDS differential pair.
Multiplexed with DDI3_PAIR0+ and DDI3_PAIR0-.
HDMI/DVI Hot-plug detect.
Multiplexed with DDI3_HPD.
HDMI/DVI I 2 C Control Clock
Multiplexed with DDI3_CTRLCLK_AUX+
I/O PU/PD
O PCIE
O PCIE
O PCIE
O PCIE
I PCIE PD 1M
I/O OD 3.3V PD 100k
I/O OD 3.3V PU 100k
3.3V
O PCIE
O PCIE
O PCIE
O PCIE
I PCIE PD 1M
I/O OD 3.3V PD 100k
I/O OD 3.3V PU 100k
3.3V
O PCIE
O PCIE
O PCIE
O PCIE
I PCIE
I/O OD 3.3V
TU87m12
Comment
HDMI1_CTRLDATA is a boot strap signal (see note below).
HDMI enable strap already populated
HDMI2_CTRLDATA is a boot strap signal (see note below).
HDMI enable strap is already populated.
Not supported
Not supported
Not supported
Not supported
Not supported
Not supported
65/114
