Congatec COM Express conga-TC87 User Manual page 59

Pin Row A
USB_6_7_OC#
A38
A39 USB4-
A40 USB4+
A41 GND (FIXED)
A42 USB2-
A43 USB2+
USB_2_3_OC#
A44
A45 USB0-
A46 USB0+
VCC_RTC
A47
EXCD0_PERST#
A48
EXCD0_CPPE#
A49
LPC_SERIRQ
A50
A51 GND (FIXED)
PCIE_TX5+ (*)
A52
PCIE_TX5- (*)
A53
A54 GPI0
PCIE_TX4+ (*)
A55
Note
The signals marked with asterisk symbol (*) are not supported on the conga TC87.
Copyright © 2013 congatec AG
Pin Row B Pin
USB_4_5_OC#
B38 A93
B39 USB5- A94
B40 USB5+ A95
B41 GND (FIXED) A96
B42 USB3- A97
B43 USB3+ A98
USB_0_1_OC#
B44 A99
B45 USB1- A100 GND (FIXED)
A101 SER1_TX
B46 USB1+
EXCD1_PERST# A102 SER1_RX
B47
EXCD1_CPPE# A103 LID#
B48
SYS_RESET# A104 VCC_12V
B49
CB_RESET# A105 VCC_12V
B50
A106 VCC_12V
B51 GND (FIXED)
PCIE_RX5+ (*) A107 VCC_12V
B52
PCIE_RX5- (*) A108 VCC_12V
B53
A109 VCC_12V
B54 GPO1
PCIE_RX4+ (*)
B55 A110 GND (FIXED)
Row A Pin
GPO0 B93
SPI_CLK
B94
SPI_MOSI
B95
TPM_PP
B96
TYPE10#
B97
SER0_TX
B98
SER0_RX
B99
B100 GND (FIXED)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP#
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND (FIXED)
TU87m12
Row B
VGA_HSYNC (*)
VGA_VSYNC (*)
VGA_I2C_CK (*)
VGA_I2C_DAT (*)
SPI_CS#
RSVD
RSVD
59/114
