Feature
Ch Hash Mask
Ch Hash Interleaved Bit BIT06, BIT07, BIT08,
NMode Support
Memory Scrambler
RMT Crosser Support
MRC Fast Boot
DIMM Exit Mode
Power Down Mode
Memory Remap
GDXC Support
11.5.2.3

GT - Power Management Control Submenu

Feature
Processor Graphics
Controller Info
RC6(Render Standby)
GT Overclocking
Support
GT Overclocking
Frequency
GT Overclocking
Voltage
Copyright © 2013 congatec AG
Options Description
Set the bit(s) to be included in the XOR function. Note: Bit mask corresponds to bits[19:6].
1-0x3FFF
Default : 0x30CE
Select the bit to be used for channel interleaved mode. Note: BIT07 will interleave the channels at a 2
BIT09 cacheline granularity, BIT08 at 4 and BIT09 at 8.
Auto NMode support option
1N Mode
2N Mode
Enabled Enable or disable memory scrambler support.
Disabled
Enabled Enable or disable RMT crosser support.
Disabled
Enabled Enable or disable MRC fast boot.
Disabled
Auto DIMM Exit Mode control
Slow Exit
Fast Exit
No Power Down Power Down Mode control
APD Default is:
PPD Auto - when DIMM Exit Mode is set to Slow Exit and
PPD-DLLoff PPD - when DIMM Exit Mode is set to Fast Exit.
APD-PPD
Auto
Enabled Enable or disable memory remap above 4G.
Disabled
Enabled Enable or disable GDXC support.
Disabled
Options Description
no option Displays the Processor Graphics Controller Info.
Disabled Check to enable render standby support.
Enabled
Disabled Enable or disable GT overclocking support.
Enabled
0-255 Overclocked RP0 frequency (MLCClk) in multiples of 50 MHz.
Default : 22
0-255 Extra voltage needed above the original RP0 voltage. The unit is 1/256 volt.
Default : 0
TU87m12 106/114
