11.4.16.1

Console Redirection Settings Submenu

Feature
Terminal Type
Baudrate
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key Support
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Resolution
Putty KeyPad
Redirection After BIOS POST
Copyright © 2013 congatec AG
Options Description
VT100 Select terminal type.
VT100+
VT-UTF8
ANSI
9600, 19200, 38400, Select baud rate.
57600, 115200
7, Set number of data bits.
8
None Select parity.
Even
Odd
Mark
Space
1 Set number of stop bits.
2
Select flow control.
None
Hardware RTS/CTS
Disabled Enable VT-UTF8 combination key support for ANSI/VT100 terminals
Enabled
Disabled With recorder mode enabled, only text output will be sent over the terminal. This is helpful to capture and
Enabled record terminal data.
Disabled Enables or disables extended terminal resolution.
Enabled
80x24 Number of rows and columns supported for legacy OS redirection.
80x25
VT100 Select FunctionKey and KeyPad on Putty.
LINUX
XTERMR6
SCO
ESCN
VT400
Enabled Select whether serial redirection should be continued after POST.
Disabled
TU87m12 100/114
