Signal
Pin # Description
PEG_TX0+
D52
PEG_TX0-
D53
PEG_TX1+
D55
PEG_TX1-
D56
PEG_TX2+
D58
PEG_TX2-
D59
PEG_TX3+
D61
PEG_TX3-
D62
PEG_TX4+
D65
PEG_TX4-
D66
PEG_TX5+
D68
PEG_TX5-
D69
PEG_TX6+
D71
PEG_TX6-
D72
PEG_TX7+
D74
PEG_TX7-
D75
PEG_TX8+
D78
PEG_TX8-
D79
PEG_TX9+
D81
PEG_TX9-
D82
PEG_TX10+
D85
PEG_TX10-
D86
PEG_TX11+
D88
PEG_TX11-
D89
PEG_TX12+
D91
PEG_TX12-
D92
PEG_TX13+
D94
PEG_TX13-
D95
PEG_TX14+
D98
PEG_TX14-
D99
PEG_TX15+
D101
PEG_TX15-
D102
PEG_LANE_RV# D54
Note
The PCI Express Graphics interface is not supported on the conga-TC87.
Copyright © 2013 congatec AG
PCI Express Graphics Transmit Output differential pairs.
Note: Can also be used as PCI Express Transmit Output differential pairs 16 through 31
known as PCIE_TX[16-31] + and -.
PCI Express Graphics lane reversal input strap. Pull low on the carrier board to reverse lane
order.
TU87m12
I/O
PU/PD
Comment
O PCIE
Not supported.
I
PU 10k 3.3V Not supported.
62/114
