TIG program sequence ("Program steps" mode)

5.9.7.1

TIG parameter overview

Basic parameters
Item Meaning/explanation
1 Gas pre-flow time
2 P
START
Ignition current
3 Duration (start program)
4 Slope duration from P
5 P (main program)
A
Welding current, absolute
6 Duration (P
7 P (reduced main program)
B
Welding current
8 Duration (reduced main program)
9 Slope duration from P
10 P (end program)
END
Welding current
11 Duration (end program)
12 Gas post-flow time
13 Superpulsing
P , P , and P
START B
general welding current setting.
099-005033-EW501
15.01.2010
2 4
sec
3
1
13
sec
Super-
puls
to P
START A
)
A
to P
A END
are relative programs whose welding current settings are a percentage based on the
END
8
DYN
sec
sec
5
6
sec
7
Figure 5-44
Design and function
9
10
sec
sec sec
11 12
Setting range
0 s to 0.9 s
0% to 200%
0 s to 20 s
0 s to 20 s
5 A to 550 A
0.01 s to 20.0 s
1% to 100%
0.01 s to 20.0 s
0 s to 20 s
1% to 100%
0 s to 20 s
0 s to 20 s
on/off
TIG welding
