5.25-Inch Drive - Compaq AP200 Maintenance And Service Manual

5.25-Inch Drive

To remove a 5.25-inch drive:
1. Perform the service preparations shown on page 3-2.
2. Remove the access panel.
3. Remove the front bezel.
4. Disconnect the power
3
2
Figure 3-15. Disconnecting the cables
CAUTION: Before removing the access panel, ensure that the workstation is
turned off, all cables are disconnected from the back of the workstation, and the
power cord is disconnected from the grounded AC outlet.
1 2
, data , and audio
3
cables from the back of the drive.
1
Compaq Professional Workstation AP200 Maintenance and Service Guide
