8.4-GB Ultra ATA Hard Drive
Drive Size:
Configuration
Single (Standard Installation)
Dual Master
Dual Slave
Cable Select (Shipping Configuration)
Single (Neutral Position)
Jumper NOT Installed
Key
Jumper Installed
Figure 6-6. Jumper positions for the 8.4-GB hard drive (ST38641A)
8.4 GB
Model:
5
3
1
6
4
2
IDE Settings
ST38641A
1-2
3-4
Compaq Professional Workstation AP200 Maintenance and Service Guide
6-7
5-6
