32X Max CD-ROM Drive (IDE
Dimensions
Height
Width
Depth
Weight
Audio Interface
Line Out Connector
RMS Output Voltage
S/N Ratio
Channel Separation
Noise
Frequency Response
Digital Audio Out Connector
Electrical
DC Power Requirements
5 VDC +/-5%
12 VDC +/-5%
DC Current
5 VDC +/-5% (typical)
5 VDC =/-5% (maximum)
12 VDC +/-5% (typical)
12 VDC =/-5% (maximum)
Total Drive Power (Stand-by Mode) < 1 W
) Continued
42.9 mm
150.1 mm
208.0 mm
1200 g
0.7 Vrms
80 dB
65dB
0.1%
20 to 20 kHz
2 pin digital audio out connector described in the ATAPI spec., 2.6, section
11.1 must be included. This serial digital audio out must conform to the
IEC-958 EIAJ CP-1201 format.
100 mV ripple p-p
200 mV ripple p-p
450 mA
1800 mA
<600 mA
<1800 mA
Compaq Professional Workstation AP200 Maintenance and Service Guide
7-11
