3-36 Removal and Replacement Procedures
Converting a Minitower to a Desktop
Configuration
To convert a minitower to a desktop configuration:
1. Perform the service preparations shown on page 3-2.
2. Remove the access panel.
3. Remove the front bezel.
4. Disconnect all power and data cables from the drives in the 5.25-inch drive bays.
5. Remove the drives from the 5.25-inch drive bays by pressing drivelock.
Figure 3-37. Releasing the drives with the drivelock
CAUTION: Before removing the access panel, ensure that the workstation is
turned off, all cables are disconnected from the back of the workstation, and the
power cord is disconnected from the grounded AC outlet.
