200W Power Supply - Compaq AP200 Maintenance And Service Manual

7-8 Physical and Operating Specifications

200W Power Supply

Input Specifications
Rated Input Voltage
Rated Input Current
Rated Input Frequency
General Specifications
Input Power
Range Input Line
Holdup Time
Full Output Rating
Minimum Load
Ambient Temperature Range
Operating
Storage
Safety Standard
Input Transient Susceptibility:
Surge Tolerant Power Supply
(superimposed on AC line)
Table 7-5
200W Power Supply Specifications
115 Voltage Setting
90 to 132 VAC
5.5 A
47 to 63 Hz
310W
90 to 132 VAC
16 ms from zero crossing at
115 VAC
To 40°C and 5,000 ft.
To 32°C and 10,000 ft.
(derate linearly)
1.5A on + 5V and +3.3V outputs;
0.1A on +12V and +5V aux outputs
50° to 104°F
-40° to 149°F
rd
UL 1950 3 Edition; CSA 22.2 No. 950 3
2000V surge per IEC1000-4-5 with no abnormal operation.
230 Voltage Setting
180 to 264 VAC
3.0 A
47 to 66 Hz
310W
180 to 264 VAC
16 ms from zero crossing at
230 VAC
10° to 40°C
-40° to 65°C
rd
Edition, EN 60 950
