Audio System; Keyboard - Compaq AP200 Maintenance And Service Manual

7-16 Physical and Operating Specifications

Audio System

Sampling rate
Full Scale Input Voltage (rms)
Microphone-in
Line-in
Full Scale Output Voltage (rms)
Line Output
Dynamic Range (SNR)
Line Input-to-Line Output
Digital Playback
Digital Record
Total Harmonic Distortion
Frequency Response (-3 dB cutoffs)
Line Level (48 Khz)
Speaker
Impedence (nominal)
Microphone-in
Line-in
Headphone-out
Line-out
Data Types
PCM
A-Law
µ-Law

Keyboard

Dimensions
Height
Width
Depth
Weight
Table 7-12
Audio System
4 KHz to 48 KHz (adjustable)
0.050
1.0
1.0
-83 dB
-81 dB
-78 dB
0.060%
20 Hz to 20,000 Hz
110 Hz to 15,000 Hz
100-K ohm
100-K ohms
16 ohms (min.)
5-K ohms
8-/16-bit (mono/stereo)
8-/16-bit (mono/stereo)
8-/16-bit (mono/stereo)
Table 7-13
Compaq Enhanced Keyboard
U.S.
1.3 in
18.3 in
6.4 in
3.0 lb
Metric
3.3 cm
46.5 cm
16.1 cm
1.4 kg
