Network

Physical Connector
Operating Environment
Temperature
Humidity
Electrical Bus

RJ-45 Network Cable Specifications

The RJ-45 connections use an unshielded twisted pair (UTP) cable of 22-, 24-, or 26-gauge.
The cable must comply with the IEEE 802.3 10BASE-T standard. The maximum distance
between the computer and the hub is 100 meters.
Table 7-16
Ethernet Network Interface Controller (NIC)
RJ-45
50° to 95°F
10% to 90%, noncondensing
32-bit PCI bus
Compaq Professional Workstation AP200 Maintenance and Service Guide
10° to 35°C
