8-2 External Connectors
External Connectors
Reference
6
7
8
9
10
11
12
13
14
15
Continued
Connector
Parallel port connector
Serial port connector
Serial port connector
Video Port (AGP)
External SCSI connector
RJ-45 connector
Headphone connector
Audio line-out connector
Audio line-in connector
Microphone connector
Function
Connects a parallel device such as a printer
Connects a serial device, such as a serial printer COM 2 (B) on
top, COM 1 (A) on bottom
Connects a serial device, such as a serial printer COM 2 (B) on
top, COM 1 (A) on bottom
Connects a monitor
Connects a SCSI device
Connects to the Ethernet network
Connects to headphones
Connects an external amplifier (to power additional speakers) or a
tape deck for recording
Connects a device that supplies sound, such as a tape deck or CD
player
Connects a microphone
