Converting a Desktop to a Minitower
Configuration
To convert a desktop to a minitower configuration:
1. Perform the service preparations shown on page 3-2.
2. Remove the access panel.
3. Remove the front bezel.
4. Disconnect all power and data cables from the drives in the 5.25-inch drive bays.
5. Remove the drives from the 5.25-inch drive bays by pressing drivelock.
Figure 3-40. Releasing the drives with the drivelock
CAUTION: Before removing the access panel, ensure that the workstation is
turned off, all cables are disconnected from the back of the workstation, and the
power cord is disconnected from the grounded AC outlet.
Compaq Professional Workstation AP200 Maintenance and Service Guide
3-39
