Power Supply

To remove the power supply:
NOTE: The system fan is integrated into the power supply.
1. Perform the service preparations shown on page 3-2.
2. Remove the access panel.
3. Disconnect all power cables from the mass storage devices and the system board.
1
4. Remove the three external screws that secure the power supply to the back of the chassis
.
NOTE: The internal screw that secures the power supply to the side of the chassis may not need
to be removed, only loosened.
CAUTION: Before removing the access panel, ensure that the workstation is
turned off, all cables are disconnected from the back of the workstation, and the
power cord is disconnected from the grounded AC outlet.
Compaq Professional Workstation AP200 Maintenance and Service Guide
3-29
