3-10 Removal and Replacement Procedures
5. Press the drivelock to unlock the hard drive.
Figure 3-10. Releasing the drive with the drivelock
6. While pressing the drivelock, pull the drive out of the drive bay.
Figure 3-11. Removing a 3.5-inch hard drive
7. Remove the two guide screws from each side of the drive.
To replace the 3.5-inch hard drive, install two guide screws on each side of the replacement
drive, be sure the guide screws line up with the guide slots, and slide the drive into the drive
bay until it snaps into place.
IMPORTANT: When installing a second Ultra ATA hard drive on the primary controller, you
must use an 80-conductor Ultra ATA cable for optimal performance. This cable is included
in the hard drive option kit.
