Switch Settings

The following illustration shows the location of Switch 1. Switch 1 controls the CPU/clock
speed as well as the Power-On Password/Setup Password.
S1 on switch 1 enables the Power-On Password/Setup Password. The default is OFF. To reset
the password, turn this switch ON.
Figure 6-2. System Board SW1 location
350/100 MHz
400/100 MHz
450/100 MHz
NOTE: S1 OFF = Password enabled (default)
ON
ON
Table 6-2
SW1 Settings
S1 S2 S3
OFF OFF OFF
OFF ON ON
OFF ON OFF
Compaq Professional Workstation AP200 Maintenance and Service Guide
350 MHz
1 2 3 4 5 6
400 MHz
ON
1 2 3 4 5 6
450 MHz
1 2 3 4 5 6
S4 S5
ON ON
OFF ON
OFF ON
6-3
S6
OFF
OFF
OFF
