Installing an Internal Hard Disk Drive

007-4772-002
To install a disk drive, follow these steps:
1. Open the bezel door. If there is an empty drive sled in the drive bay, remove it. To
remove the drive sled, press in on the right side of the locking handle; the handle
will unlatch from the enclosure. Swing the handle all the way open; then slide the
drive sled out of the enclosure.
2. Move the handle on the drive you are installing to the fully open position. Then
position the drive sled so that it engages the drive bay guide rails (see Figure 3-12).
Note: If there is only one disk drive in your system, it must be located in the lower drive
bay.
3. Gently push the drive sled into the drive bay until the locking handle engages with
left side of the bay opening. Then swing the locking handle towards the enclosure
until it latches (see Figure 3-12).
Installing or Removing Internal Hard Disk Drives
65
