3: Maintenance and Upgrade Procedures
86
3. Tilt the front end of the PCI board upward until it clears the edge of the chassis.
Remove the PCI board from the enclosure and place it in a safe location (see
Figure 3-28).
U S
B
1
2
3
L 1
U P
4
L IN
K
B 1 -S
1
B 2 -S
2
B 2 -S
1
B 3 -S
2
B 3 -S
1
B 4 -S
2
B 4 -S
1
A G
P -6
A G
P -5
Figure 3-28 Removing a PCI Board
4. If you will be replacing the PCI board, see "Installing a PCI Board" on page 81.
5. If you are finished removing PCI boards, close the PCI gate. Then install the three
screws that secure the gate to the enclosure.
This completes the PCI board removal. To return the system to service, refer to
"Returning the System to Service" on page 52.
PCI board installed
in PCI bus 2, slot 1
007-4772-002
