Figure 2-4 System Base I/O Board External Connectors - Silicon Graphics Prism Hardware User's Manual

007-4772-002
USB
1
2
Figure 2-4 System Base I/O Board External Connectors
The 36-pin MDR serial connector on the base I/O board can connect to multiple serial
devices by way of the serial adapter cable shown in Figure 2-5 on page 26. Leave the
serial adapter cable unplugged if you are not connecting any serial devices to the system.
