Installing a PCI Board
007-4772-002
Follow these steps to install a PCI board:
1.
Remove the three screws that secure the PCI gate to the enclosure; then open the
PCI gate (see Figure 3-23).
U SB
1
2
3
L1
4
U PL
IN K
B1 -S
1
B2 -S
2
B2 -S
1
B3 -S
2
B3 -S
1
B4 -S
2
B4 -S
1
AG
P- 6
AG
P- 5
PCI gate
Opening the PCI Gate
Figure 3-23
2. If another PCI board is installed in the slot where you will install the new PCI board,
you must remove it before you can install the new PCI board. See "Removing a PCI
Board" on page 84.
Installing or Removing PCI Boards
U SB
1
2
3
L1
U PL
4
IN K
B1 -S
1
B2 -S
2
B2 -S
1
B3 -S
2
B3 -S
1
B4 -S
2
B4 -S
1
AG
P- 6
AG
P- 5
81
