Installing or Removing Internal Hard Disk Drives

Installing an Internal Hard Disk Drive

007-4564-001
The Silicon Graphics Tezro visual workstation can have one or two internal hard disk
drives. These drives are sled mounted and can easily be installed and removed. The
following sections contain instructions for installing and removing hard disk drives:
• "Installing an Internal Hard Disk Drive" on page 67
• "Removing an Internal Hard Disk Drive" on page 69
Note: You do not need to prepare the system for service to install or remove hard disk
drives. If you are replacing the drive in the upper bay, ensure that it is spun down before
you remove it. If you are replacing the system disk in the lower drive bay, you must
power down the system.
To install a disk drive, follow these steps:
1. Open the bezel door. If there is an empty drive sled in the drive bay, remove it. To
remove the drive sled, press in on the right side of the locking handle; the handle
will unlatch from the enclosure. Swing the handle all the way open; then slide the
drive sled out of the enclosure.
2. Move the handle on the drive you are installing to the fully open position. Then
position the drive sled so that it engages the drive bay guide rails (see Figure 3-11).
Note: If there is only one disk drive in your system, it must be located in the lower drive
bay.
3. Gently push the drive sled into the drive bay until the locking handle engages with
left side of the bay opening. Then swing the locking handle towards the enclosure
until it latches (see Figure 3-11).
