Replacing the Rear Fan Assembly
Figure 3-32
This completes the replacement of the rear fan assembly. To return the system to service,
see "Returning the System to Service" on page 52.
Replacing Cooling System Components
Rear fan power
connection
Rear fan
retaining screw
