4: Troubleshooting and Diagnostics

Configuring Monitor Positions

Example "ServerLayout" Section for Four Monitors in a Line

Section "ServerLayout"
Identifier "Four-in-a-Line"
Screen "Screen SG-0"
Screen "Screen SG-1"
Screen "Screen SG-2"
Screen "Screen SG-3"
InputDevice "Mouse1" "CorePointer"
InputDevice "Keyboard1" "CoreKeyboard"
EndSection
132
When an X-Server is managing multiple monitors, it needs to know their relative
positions in order to properly handle cursor cross-over locations.
The monitor positions are specified in the "ServerLayout" section of the
/etc/X11/XF86Config file as follows:
Each screen is listed, followed by a list of the screens above, below, to the left, and to the
right of it (in that order). Figure 4-2 and the following subsection show an example of
four monitors arranged in a line.
Programs started by clicking on an icon appear on the screen from which you invoked
them. Note that once a program has been launched, it is not possible to move it from one
screen to another.
SG-0
Figure 4-2 Four Monitors in a Line
"" ""
"" ""
"" ""
"" ""
SG-1 SG-2
"" "Screen SG-1"
"Screen SG-0"
"Screen SG-1"
"Screen SG-2"
SG-3
"Screen SG-2"
"Screen SG-3"
""
007-4772-002
