4: Troubleshooting and Diagnostics

Configuring Monitor Types

Example "Device" Section for Use With Two Analog Monitors

Section "Device"
Identifier "SGI SG-0"
Driver "fglrx"
BusId "PCI:23:0:0"
Option "MonitorLayout" "CRT, CRT"
EndSection
134
The system graphics cards support both analog and digital monitors. The type of
monitor connected to each graphics card is specified in the "Device" sections of the
/etc/X11/XF86Config file.
Table 4-7 lists the allowable options for the MonitorLayout line. If the line is not present,
both channels default to AUTO.
Options for Monitor Layout
Table 4-7
Monitor Type Meaning
AUTO Automatically select monitor type (default)
TMDS Digital monitor
CRT Analog monitor
NONE No monitor
The format is:
Option "MonitorLayout" "
where channel1type is the type (AUTO, TMDS, CRT or NONE) of monitor attached to
channel 1 (the left DVI-I connector) for this pipe, and
channel2type is the type (AUTO, TMDS, CRT or NONE) of monitor attached to channel 2
(the right DVI-I connector) for this pipe.
channel1type channel2type
, "
