3: Maintenance and Upgrade Procedures

Removing the Enclosure Panels

Determining Which Enclosure Panels to Remove

46
This section shows you how to open the enclosure in the following sections.
• "Determining Which Enclosure Panels to Remove" on page 46
• "Removing the Left or Right Side Panel" on page 47
• "Removing the Enclosure Bezel" on page 48
To determine which side(s) of the enclosure you need to remove to access specific
components, see Table 3-1. If a part appears in two columns, you must remove both
panels in order to access that component.
Note: Table 3-1 assumes that you are looking at the front of the system.
Table 3-1 Component Access by Enclosure Panel
Right Side Panel Left Side Panel
Memory DIMMS Base I/O board
Hard Disk Drive Fan L1 display cable
Rear Fan Assembly LED cable
PCI boards
DVD-ROM drive
Fan wall
After you have determined which side(s) of the enclosure you need to open, proceed to
the appropriate section.
Front Side Panel (Bezel)
L1 display
L1 display cable
LED cable
