Figure 1-4 System Rear Panel Items - Silicon Graphics Prism Hardware User's Manual

1: Quick Start Installation and Operation Procedures
Base I/O PCI card
8
Kensington
lock slot
Graphics card
Graphics card
Figure 1-4 System Rear Panel Items
USB ports Console port
USB
1 3 CONSOLE
L1 UPLINK
2 4
B1-S1
B2-S2
B2-S1
B3-S2
B3-S1
B4-S2
B4-S1
AGP-6
AGP-5
AC power connector
IS IN IS REPEAT
ImageSync repeat port
ImageSync in port
PCI gate
007-4772-002
