3: Maintenance and Upgrade Procedures
88
4. Connect the fan wall power cable to the fan wall power connector on the interface
board.
B A
C
Slots
Figure 3-29
Replacing the Fan Wall
This completes the fan wall replacement. To return the system to service, see to
"Returning the System to Service" on page 52.
B
Slots
D
007-4772-002
