Removing the Enclosure Bezel

48
The front of the enclosure is covered by a decorative plastic bezel. The bezel is made up
of two pieces: the bezel frame and the drive shroud. The bezel frame covers the front of
the enclosure. The drive shroud mounts inside the bezel frame and covers the area
adjacent to the DVD-ROM drive and hard disk drives.
Follow these steps to remove the bezel from the front of the enclosure:
1. Open the door on the front of the bezel.
2. Remove the five screws that secure the front bezel and door assembly to the top of
the chassis.
3. Tilt the top of the bezel frame toward you slightly. Then lift the bezel and door
assembly off of the tabs that are supporting it.
4. Lift the bezel up, pull it away from the enclosure, and place it in a secure location.
